JRC JSS-2150 MF/HF GMDSS Radio
Japan Radio Co., Ltd. (JRC)
Refurbished
Original SM MARINE SERVICE™ photograph of the JRC MF/HF communication equipment set, including radio controller, data terminal, keyboard, transceiver, antenna tuner, handset and cables.
|
Specification |
Details |
|---|---|
|
Manufacturer |
Japan Radio Co., Ltd. (JRC) |
|
Country of Manufacture |
Japan, as marked on the pictured units |
|
Equipment Family |
JSS-2150 |
|
Photographed System Model |
JSS-2150N |
|
Product Type |
Marine MF/HF Radio Equipment |
|
Rated Output Power |
150 W PEP at 4–27.5 MHz |
|
DSC Capability |
Class A DSC with six-channel watchkeeping |
|
Transceiver |
NTD-2150 |
|
MF/HF Controller |
NCM-2150 |
|
Antenna Tuner |
NFC-2150 |
|
Data Terminal Shown |
NDZ-327 |
|
Handset |
NQW-261 family, as supplied |
|
Power Supply |
Nominal 24 V DC |
|
Transceiver Serial Number |
BS82424 |
|
Controller Serial Number |
BJ54001 |
|
Manufacturing Date on Transceiver |
July 2015 |
|
Condition |
Not independently verified |
|
Availability |
Complete-set and individual spare-part enquiries |
|
Shipping |
Worldwide, subject to confirmation |
The system and transceiver plates both carry serial number BS82424. The main equipment plate also displays CMIIT ID 2010AJ5191 and model JSS-2150N.
The JRC JSS-2150N MF/HF Radio Equipment is part of Japan Radio Co., Ltd.'s marine communication product family. The JSS-2150 is designed for medium-frequency and high-frequency radiotelephone communication and Digital Selective Calling (DSC).
The equipment is used aboard ships for long-range maritime communication, including distress, urgency, safety and routine calls when correctly installed and commissioned.
The photographed arrangement includes an NTD-2150 transceiver, NCM-2150 operating controller, NFC-2150 antenna tuner and data-terminal equipment.
The modular architecture is useful to marine service engineers because individual components can be identified for troubleshooting and replacement.
SM MARINE SERVICE™ supports enquiries for complete JRC MF/HF radio equipment, compatible modules, internal electronic assemblies and international marine communication spare parts.
Website: www.smmarineservice.com
Original photograph showing JSS-2150N system identification, NTD-2150 transceiver type, serial number BS82424 and Made in Japan markings.
The photographed transceiver plate specifies compass safe distances of 1.2 m for standard compasses and 0.8 m for steering compasses.
These values belong to the NTD-2150 unit and should not be substituted for the compass safe distances marked on other system components.
The JSS-2150 is a maritime radio system that supports long-range communication over medium- and high-frequency radio bands.
It combines a transceiver, controller and automatic antenna tuner. Optional data-terminal equipment allows NBDP (Narrow-Band Direct Printing) communication where fitted and properly configured.
The system provides Class A DSC with dedicated watchkeeping on six internationally designated MF/HF DSC frequencies.
The JRC radio family also supports onboard self-diagnostic functions to help identify possible equipment faults.
GMDSS compliance note: The suitability of an individual JSS-2150 installation depends on the ship's sea area, required radio fit, approvals, commissioning and operational condition. The presence of DSC or NBDP equipment alone does not establish current regulatory compliance.
150 W MF/HF radiotelephone for compatible marine installations.
Class A Digital Selective Calling (DSC).
Six-frequency DSC watchkeeping receiver.
SSB voice communication.
Automatic antenna tuning through the NFC-2150.
Separate NCM-2150 operating controller.
Optional NBDP radio telex terminal and keyboard.
Self-diagnostic capability.
Support for up to two compatible controllers.
Marine-oriented modular construction.
Optional printers, power supply and battery-charging equipment.
|
Parameter |
Specification |
|---|---|
|
System |
JRC JSS-2150 |
|
Rated RF Output |
150 W PEP at 4–27.5 MHz |
|
RF Output, 1.6–4 MHz |
100 W PEP |
|
Transmit Frequency |
1605.0–27500.0 kHz |
|
Receive Frequency |
90.0–29999.9 kHz |
|
Frequency Step |
100 Hz |
|
Frequency Stability |
Within ±10 Hz |
|
DSC Watch Frequencies |
2187.5, 4207.5, 6312.0, 8414.5, 12577.0, 16804.5 kHz |
|
Controller LCD |
3.8-inch, 320 × 240 pixels |
|
Supply |
21.6–31.2 V DC |
|
DC Consumption |
Transmit ≤30 A; Receive ≤5 A |
|
Transceiver Weight |
Approximately 13 kg |
|
Antenna Tuner Weight |
Approximately 3.3 kg |
|
Controller Weight |
Approximately 1.3 kg |
|
Communication |
Radiotelephone, DSC, optional NBDP |
|
Position Interface |
IEC 61162-1 |
|
Type Approval |
JRC publishes IMO-approved specifications for the model family |
These specifications are published by JRC for the JSS-2150 150 W model. They describe the product design, not verified operating measurements from the used equipment pictured.
The NTD-2150 is the primary transmitting and receiving unit of the system. It provides the RF communication functions and integrates with the operating controller and antenna tuner.
The pictured equipment is marked:
Model: NTD-2150
Serial number: BS82424
Manufacturer: Japan Radio Co., Ltd.
Made in Japan
Its connections include the watchkeeping/receiving antenna interface, grounding and the associated system connections.
NTD-2150 transceiver reference. The actual SM MARINE SERVICE™ equipment is shown in the original photographs.
Original photograph showing the NCM-2150 controller, handset, rear connections and surrounding transceiver equipment.
The NCM-2150 provides the operator interface for the MF/HF system. It includes an LCD, keypad, communication controls and a protected distress-alert button.
The controller's nameplate identifies:
|
Identification |
Value |
|---|---|
|
Model |
NCM-2150 |
|
Serial Number |
BJ54001 |
|
Standard Compass Distance |
2.0 m |
|
Steering Compass Distance |
1.5 m |
|
Manufacturer |
Japan Radio Co., Ltd. |
The rear panel includes connections labelled EXT SP, EXT MODEM and PRN-C, together with other controller interface connections.
JRC documentation identifies the 7ZCJD0343 controller cable as a 5 m connection cable.
Original SM MARINE SERVICE™ photograph showing the JRC antenna tuner assembly, enclosure and manufacturer label.
The NFC-2150 is the automatic antenna tuner associated with the 150 W JSS-2150 system.
It adjusts the matching arrangement between the transceiver and the installed transmitting antenna for supported operating frequencies.
JRC's published specification identifies the tuner as approximately 3.3 kg.
The tuner contains a designated matching assembly, CFG-2150, which is an important identifier when purchasing internal replacement components.
The original complete-set photograph shows an NDZ-327 DATA TERMINAL.
The supplied product notes refer to NDZ-227, which appears in JRC documentation for the NBDP option. However, the actual display marking in the photograph should take priority when identifying this particular unit.
The NDZ-327 must therefore be quoted as the photographed model. Its compatibility and installed NBDP configuration require separate verification.
An accompanying keyboard is visible in the complete-set photograph. The supplied product information identifies the NDF-369 keyboard family, but the keyboard's own type label should be checked before assigning that model to the photographed item.
The NQW-261 handset is part of the standard controller equipment identified in JRC's system documentation.
The handset permits voice communication through the MF/HF radiotelephone.
Buyers should verify the handset model and connector arrangement when ordering it separately.
The JSS-2150 system includes multiple repairable electronic assemblies. JRC's service documentation identifies the following repair-unit numbers.
|
Equipment |
Board / Unit |
Part Number |
|---|---|---|
|
NTD-2150 |
Power Amplifier Unit |
CAH-2415 |
|
NTD-2150 |
TRX Unit |
CMN-2250 |
|
NTD-2150 |
Watch Receiver Modem |
CMJ-2250 |
|
NTD-2150 |
Power Supply Unit |
CBD-2415 |
|
NTD-2150 |
Terminal Unit |
CQD-2415 |
|
NTD-2150 |
Extension Board |
CQD-2416 |
|
NCM-2150 |
Control Unit |
CDJ-3775 |
|
NCM-2150 |
AF Control Unit |
CMV-3775 |
|
NCM-2150 |
LCD Unit |
CDE-3770 |
|
NCM-2150 |
Main Panel Unit |
CCK-3775 |
|
NCM-2150 |
Sub Panel Unit |
CCK-3776 |
|
NFC-2150 |
Matching Unit |
CFG-2150 |
These are documented component identifiers for the JSS-2150 equipment family. None should be described as an individually photographed or available PCB without checking actual board markings and stock.
The JRC JSS-2150 is used for marine MF/HF voice and DSC communications aboard suitably equipped vessels.
Relevant applications include ship-to-shore communication, vessel-to-vessel communication, distress and safety communications, DSC watchkeeping and optional NBDP radio telex operations.
Equipment in this category is commonly fitted aboard merchant vessels such as tankers, bulk carriers, container vessels and other SOLAS-class ships where the required communication arrangement calls for MF/HF facilities.
The exact GMDSS sea-area suitability must be evaluated against the complete approved radio installation.
|
Fault |
Possible Cause |
Recommended Check |
|---|---|---|
|
No power |
Supply or internal power fault |
Check approved DC supply and connections |
|
No transmission |
PA, RF control or antenna issue |
Review transmission diagnostics |
|
Low transmitter power |
PA or antenna matching problem |
Arrange qualified RF performance testing |
|
Antenna tuner fails |
Tuner, connection or antenna problem |
Check tuner status and approved installation |
|
DSC watchkeeping fault |
Watch receiver or interface issue |
Check DSC diagnostic status |
|
Controller LCD blank |
Supply, display or controller fault |
Examine controller power and status |
|
Controller unresponsive |
Interface or internal electronic issue |
Check cable and communication status |
|
NBDP terminal fails |
Data terminal, interface or software issue |
Investigate approved NBDP configuration |
|
Poor reception |
Antenna, RF interference or receiver problem |
Check antenna system and receiver status |
These are possible fault categories, not a diagnosis of the supplied radio system.
A qualified marine radio technician should record the exact model, serial numbers and fault information before carrying out inspection.
The technician should verify the approved supply voltage, equipment connections, transceiver/controller communication and antenna tuner status.
JRC's self-diagnostic functions can assist fault investigation; results should be recorded and interpreted using the correct service procedures.
High-power MF/HF equipment may create dangerous RF voltages and radiation hazards. Do not touch antenna components or dismantle energized radio equipment. Distress-alert controls must never be operated casually for testing.
Inspect controller, transceiver and tuner enclosures for damage.
Check accessible cables and connectors for corrosion or wear.
Record power supply and equipment status during maintenance.
Test MF/HF communication functions using approved procedures.
Check DSC watchkeeping and related indications.
Inspect antenna tuner mounting and cable condition.
Preserve equipment configuration and installation records.
Use correctly identified replacement units and PCB assemblies.
Arrange appropriate GMDSS radio inspections and operational tests.
The photographs show cables with exposed conductors around the equipment. These should be treated as requiring inspection and proper termination before any commissioning or electrical test.
SM MARINE SERVICE™ supports international enquiries for complete JRC JSS-2150 MF/HF GMDSS Radio Equipment and separately identified spare units.
The supplied stock description indicates the availability of a complete set and individual units, subject to confirmation.
Relevant spare parts include:
NTD-2150 MF/HF transceiver.
NCM-2150 operating controller.
NFC-2150 antenna tuner.
NDZ-327 pictured data terminal.
Compatible keyboard and handset.
NBD-2150 optional power supply.
NBB-724 / NBB-714 battery chargers.
CAH-2415 PA unit.
CMN-2250 TRX unit.
CMJ-2250 watch receiver modem unit.
CFG-2150 matching unit.
Compatible LCD, controller, interface and power boards.
Depending on availability, SM MARINE SERVICE™ supports sourcing enquiries for new, used, refurbished, reconditioned and tested-working equipment.
Customers should provide the JSS system version, required unit number, serial-number photograph, installed configuration, reported fault and delivery destination.
When requesting an internal PCB, include the full board part number and revision marking.
Worldwide sourcing enquiries: www.smmarineservice.com
MF/HF systems continue to provide important long-range maritime communication functions and are used as part of approved ship communication arrangements.
For ships already equipped with a JSS-2150 installation, compatible replacement modules may help maintain the original system without extensive changes to established wiring, antenna components and operator arrangements.
A suitable replacement must still meet the ship's current communication and regulatory requirements. Existing model compatibility does not automatically guarantee approval of a replacement installation.
It is a 150 W MF/HF marine radio equipment system supporting radiotelephone communication and Class A DSC.
JSS-2150N is the model designation visible on the supplied system's equipment nameplate.
It is the main MF/HF transceiver unit used in the JSS-2150 system.
It is the MF/HF operating controller used to manage communication functions.
It is the automatic antenna tuner associated with the JSS-2150 transceiver system.
Yes. JRC documentation confirms Class A DSC and six-channel DSC watchkeeping.
An NBDP configuration is available with the appropriate data-terminal and accessory equipment.
They should not be assumed identical. The photographed display is marked NDZ-327, while NDZ-227 is identified in the supplied information for another documented NBDP configuration.
CAH-2415 is the documented PA repair unit for the NTD-2150 transceiver.
Possible causes include antenna connection problems, tuner component faults or incorrect matching conditions.
Contact SM MARINE SERVICE™ with the exact model, part number and equipment photographs.
The company accepts international sourcing and shipping enquiries subject to availability and delivery arrangements.
The JRC JSS-2150N 150 W MF/HF GMDSS Radio Equipment is a marine communication system manufactured by Japan Radio Co., Ltd. The photographed set includes an NTD-2150 transceiver, NCM-2150 controller, NFC-2150 automatic antenna tuner, NDZ-327 data terminal, handset, keyboard and associated cables. The JSS-2150 family provides MF/HF radiotelephone communication, Class A DSC and optional NBDP functionality. SM MARINE SERVICE™ supports international enquiries for complete equipment, individual replacement units, internal PCBs, power supplies and related radio spare parts. Confirm the product condition, exact component identification, compatibility and approval requirements before ordering.
Marine Automation & Navigation Equipment Supplier
Available Equipment Conditions:
New Equipment • Used Equipment • Refurbished Equipment • Reconditioned Equipment
Specific product condition and availability are subject to confirmation.
Stock Locations:
Bangladesh • China
Services:
Worldwide Shipping • Technical Support • Spare Parts Supply • Marine Equipment Sourcing
Contact Information
SM MARINE SERVICE™
Samir Market, DT Road, Pahartali, beside CDA Market, Chattogram, Bangladesh
Mobile / WhatsApp / Viber: +88 01818 929292
Email: info@smmarineservice.com
Website: www.smmarineservice.com
For quotations regarding JRC JSS-2150N complete equipment, NTD-2150 transceivers, NCM-2150 controllers, NFC-2150 antenna tuners, compatible electronic boards and other marine communication spare parts, contact SM MARINE SERVICE™ with the equipment identification and shipping destination.
