VOLCANO FLAME MONITOR AFD MODEL
INTRODUCTION
The Volcano Flame Monitor AFD Model is a critical safety device used in marine and industrial combustion systems for continuous flame supervision and burner protection. Manufactured in Japan by Volcano Co., Ltd., this flame monitoring unit is designed to detect burner flame conditions and provide immediate protective action in the event of flame failure.
Onboard ships, boilers and combustion equipment operate under demanding conditions where safe and reliable flame detection is essential. A flame monitor continuously verifies the presence of a stable flame during operation. If the flame becomes unstable or extinguishes unexpectedly, the flame monitor initiates an alarm or shutdown sequence through the burner management system to prevent dangerous fuel accumulation and potential explosions.
The Volcano Flame Monitor AFD Model has earned a strong reputation throughout the marine industry due to its reliability, compact design, and dependable performance in auxiliary boilers, composite boilers, thermal oil heaters, incinerators, and other combustion applications.
Shipowners, ship managers, chief engineers, and maintenance personnel rely on flame monitoring systems as an essential part of vessel safety, machinery protection, and operational reliability.
PRODUCT OVERVIEW
The Volcano Flame Monitor AFD Model forms part of a complete burner management and combustion control system. Its primary responsibility is to continuously verify that a valid flame signal exists whenever fuel is being supplied to the burner.
The system receives signals from flame detection sensors installed on the burner assembly. These sensors monitor flame characteristics and transmit information to the flame monitor. If a proper flame signal is detected, the burner sequence continues operating normally. If the flame disappears or becomes unstable, the monitor immediately initiates a shutdown procedure to protect the boiler and associated equipment.
The Flame Monitor is commonly installed in:
- Marine Auxiliary Boilers
- Composite Boilers
- Thermal Oil Heaters
- Exhaust Gas Boilers
- Marine Incinerators
- Industrial Burner Systems
- Combustion Control Systems
The compact construction allows installation within boiler control panels and burner management cabinets where space is limited. The AFD Model is widely recognized as a dependable component within Volcano boiler automation systems.
For vessel operators, reliable flame monitoring reduces operational risks, protects expensive machinery, minimizes downtime, and ensures compliance with safety requirements.
KEY FEATURES
Continuous Flame Supervision
The Volcano Flame Monitor continuously monitors burner flame conditions and verifies proper combustion throughout the operating cycle.
Automatic Flame Failure Protection
In the event of flame loss, the system immediately triggers safety actions through the burner management system, preventing unsafe fuel accumulation.
High Reliability
The unit is designed to operate reliably in harsh marine environments where vibration, humidity, temperature fluctuations, and continuous operation are common.
Marine Application Design
The Flame Monitor is specifically suitable for marine boiler systems and combustion equipment operating onboard commercial vessels.
Compact Construction
The compact housing allows easy installation inside burner control panels and machinery control cabinets.
Enhanced Boiler Safety
By continuously verifying combustion conditions, the system significantly improves boiler operational safety and equipment protection.
Long Service Life
Japanese engineering and robust construction contribute to long operational life and dependable performance.
TECHNICAL SPECIFICATIONS
| Parameter | Description |
|---|---|
| Product Name | Flame Monitor |
| Brand | Volcano |
| Model | AFD Model |
| Manufacturer | Volcano Co., Ltd. Japan |
| Equipment Type | Flame Monitoring Device |
| Function | Flame Detection and Burner Protection |
| Supply Voltage | AC 200/220V |
| Frequency | 50/60Hz |
| Installation | Boiler Control Panel |
| Application | Marine and Industrial Burners |
| Protection Function | Flame Failure Shutdown |
| Industry | Marine Automation and Combustion Control |
Actual technical specifications should be verified from the original nameplate, service manual, or manufacturer documentation.
APPLICATIONS
The Volcano Flame Monitor AFD Model is widely used onboard various vessel types and industrial facilities.
Container Ships
Installed in auxiliary boiler systems to ensure safe burner operation during cargo and voyage operations.
Bulk Carriers
Used in boiler automation systems providing reliable flame monitoring and combustion supervision.
Oil Tankers
Supports cargo heating systems and auxiliary boiler installations requiring continuous flame verification.
Chemical Tankers
Ensures safe operation of thermal systems and combustion equipment.
LNG Carriers
Provides burner protection for critical heating and auxiliary systems.
LPG Carriers
Supports combustion safety and burner management operations.
Offshore Vessels
Used in thermal oil heaters, utility boilers, and industrial heating systems.
Passenger Ships
Protects boiler installations supporting accommodation and utility services.
Research Vessels
Provides safe combustion monitoring for specialized onboard equipment.
Fishing Vessels
Supports heating and boiler systems requiring reliable flame detection.
The Volcano Flame Monitor may operate together with:
- Marine Automation Systems
- Boiler Control Systems
- Alarm Monitoring Systems
- Engine Monitoring Systems
- Power Management Systems
- Integrated Automation Systems
- Emergency Shutdown Systems
SPARE PARTS SUPPORT
SM MARINE SERVICE™ provides support for sourcing and supplying Volcano Flame Monitor spare parts and associated boiler automation components.
Available support may include:
- Flame Monitors
- Flame Sensors
- UV Flame Detectors
- Flame Amplifiers
- Burner Controllers
- Ignition Transformers
- Ignition Electrodes
- Combustion Control Modules
- Boiler Automation Components
- Burner Management System Parts
- Replacement Monitoring Units
Both replacement units and reconditioned equipment may be available depending on customer requirements and stock availability.
REPAIR AND TECHNICAL SERVICES
SM MARINE SERVICE™ offers professional repair, testing, calibration, troubleshooting, and technical support services for Volcano Flame Monitor systems.
Troubleshooting
Diagnosis of flame detection failures, burner lockouts, communication issues, sensor problems, ignition sequence faults, and control circuit abnormalities.
Repair
Professional repair services for flame monitors, burner controllers, electronic modules, and associated combustion control equipment.
Calibration
Verification and adjustment of flame detection sensitivity and monitoring performance.
Testing
Comprehensive functional testing to ensure reliable operation under actual working conditions.
Overhaul
Complete inspection, cleaning, refurbishment, component replacement, and operational verification.
Technical Documentation Support
Support may be available for:
- User Manual
- Service Manual
- Installation Manual
- Wiring Diagram
- Technical Documentation
- Maintenance Procedures
- Troubleshooting Guides
Workshop and Onboard Service
Our experienced engineers provide both workshop repair services and onboard attendance worldwide.
WHY CHOOSE SM MARINE SERVICE™
SM MARINE SERVICE™
Bangladesh Office
Samir Market, DT Road, Pahartali, Beside CDA Market, Chattogram, Bangladesh
China Warehouse and Support Center
Shanghai, China
SM MARINE SERVICE™ supplies both New Equipment and Reconditioned Equipment depending on customer requirements and budget.
We provide worldwide supply, sourcing, repair, calibration, technical support and spare parts services for marine automation, navigation, communication and marine electronic systems.
Website : https://www.smmarineservice.com
Email : info@smmarineservice.com
WhatsApp and Viber : +8801818929292
Marketing Contact: Nazmul Hasan Bhuiyan
Mobile WhatsApp and Viber : +8801730296909
CONCLUSION
The Volcano Flame Monitor AFD Model is an essential safety component within marine boiler and burner management systems. Its ability to continuously supervise combustion conditions, detect flame failures, and initiate protective actions makes it a vital part of safe vessel operation.
For Volcano Flame Monitor supply, repair, calibration, troubleshooting, spare parts, technical support, reconditioned equipment, and worldwide marine services, contact SM MARINE SERVICE™. Our team is ready to support shipowners, ship managers, marine engineers, and vessel operators with professional marine automation and combustion control solutions worldwide.
