Manufacturer Information

Manufacturer: IHI Corporation

Country of Origin: Japan

Product Type: Radial Piston Hydraulic Motor / Marine Crane Hydraulic Motor

Applications:

• Marine Deck Cranes
• Offshore Cranes
• Cargo Handling Cranes
• Winches
• Deck Machinery
• Heavy Lifting Systems
• Offshore Equipment

SM MARINE SERVICE™ supplies IHI hydraulic motors, spare parts, repair support, reconditioned units, and technical assistance for marine and offshore customers worldwide.

---

Introduction to IHI HVL & HVK Hydraulic Motors

The IHI HVL and HVK series hydraulic motors are among the most widely used heavy-duty hydraulic drive motors installed on marine deck cranes, offshore cranes, cargo handling equipment, winches, and deck machinery systems.

These motors are designed to provide:

• High starting torque
• Smooth low-speed operation
• Excellent load holding performance
• Long service life
• Reliable operation under harsh marine conditions

Because of their rugged design and proven performance, many shipowners continue to operate HVL and HVK hydraulic motors even after decades of service.

---

IHI HVL Series Hydraulic Motors

The HVL Series is mainly used for hoisting and winch applications where high torque and reliable operation are required.

Typical HVL Series Models:

• HVL-SS
• HVL-DSS
• HVLP
• HVLG
• HVLK
• HVL-STS

---

IHI HVL-SS Hydraulic Motor

The HVL-SS model is one of the most common hydraulic motors found in marine deck crane hoisting systems.

Main Features:

• High torque output
• Compact construction
• Smooth speed control
• Heavy-duty marine design

Applications:

• Deck Cranes
• Offshore Cranes
• Cargo Handling Systems
• Marine Winches

Typical HVL-SS Hydraulic Motor

SM MARINE SERVICE™ supports supply, repair and sourcing of HVL-SS hydraulic motors and spare parts.

---

IHI HVL-DSS Hydraulic Motor

The HVL-DSS variant is designed for applications requiring higher operational flexibility and improved torque characteristics.

Main Features:

• Heavy-duty construction
• High load capacity
• Stable low-speed performance
• Long operational life

Applications:

• Offshore lifting systems
• Heavy cargo cranes
• Shipboard cranes

Typical HVL-DSS Hydraulic Motor

---

IHI HVLP Hydraulic Motor

The HVLP model is frequently installed in precision-controlled lifting systems.

Main Features:

• Precise speed control
• Stable operation
• High efficiency
• Low maintenance requirements

Applications:

• Precision cargo handling
• Offshore lifting equipment
• Marine cranes

Typical HVLP Hydraulic Motor

---

IHI HVLG Hydraulic Motor

The HVLG hydraulic motor is engineered for large-capacity lifting systems where high torque output is essential.

Applications:

• Heavy-duty offshore cranes
• Large cargo cranes
• Industrial marine lifting equipment

Typical HVLG Hydraulic Motor

---

IHI HVLK Hydraulic Motor

The HVLK model is often installed in deck machinery systems requiring continuous operation.

Main Features:

• High reliability
• Long service intervals
• Excellent torque performance

Applications:

• Continuous duty cranes
• Winches
• Deck equipment

Typical HVLK Hydraulic Motor

---

IHI HVL-STS Hydraulic Motor

The HVL-STS hydraulic motor is designed for specialized heavy-duty marine applications.

Main Features:

• High load handling capability
• Marine corrosion resistance
• Stable operation under varying loads

Applications:

• Offshore support vessels
• Heavy lifting cranes
• Marine handling systems

Typical HVL-STS Hydraulic Motor

---

IHI HVK Series Hydraulic Motors

The HVK Series is another highly successful IHI hydraulic motor family commonly installed on marine cranes and offshore lifting equipment.

Common Models:

• HVK
• HVK-DSS

---

IHI HVK Hydraulic Motor

The standard HVK hydraulic motor is designed for high-performance crane applications.

Main Features:

• High torque output
• Reliable low-speed performance
• Marine-grade construction

Applications:

• Deck Cranes
• Offshore Cranes
• Heavy Winches
• Cargo Handling Systems

Typical HVK Hydraulic Motor

---

IHI HVK-DSS Hydraulic Motor

The HVK-DSS model is used in demanding heavy-load applications where enhanced performance and durability are required.

Main Features:

• Heavy-duty marine design
• High shock load resistance
• Long operational life

Applications:

• Offshore lifting systems
• Heavy cargo cranes
• Specialized marine machinery

Typical HVK-DSS Hydraulic Motor

---

Common Spare Parts for IHI HVL & HVK Motors

Frequently required spare parts include:

• Shaft Assemblies
• Bearings
• Seal Kits
• Piston Assemblies
• Cylinder Blocks
• Valve Plates
• Rotary Groups
• Wear Plates
• O-Rings
• Repair Kits
• Overhaul Kits

SM MARINE SERVICE™ supports sourcing of both genuine and replacement spare parts for IHI hydraulic motors.

---

Common Problems and Troubleshooting

Low Torque Output

Possible Causes:

• Internal leakage
• Worn pistons
• Damaged valve plate

Hydraulic Oil Leakage

Possible Causes:

• Damaged seals
• Worn shaft seals
• Excessive system pressure

Excessive Noise

Possible Causes:

• Bearing damage
• Air contamination
• Cavitation

Overheating

Possible Causes:

• Dirty oil
• High load operation
• Internal wear

---

Maintenance Recommendations

To maximize service life:

• Inspect oil condition regularly
• Replace filters on schedule
• Monitor operating temperature
• Check shaft seals periodically
• Perform vibration inspections
• Conduct periodic hydraulic testing

---

Why Many Ships Still Use IHI HVL & HVK Motors

The IHI HVL and HVK series remain popular because they offer:

• Proven reliability
• High torque output
• Long service life
• Easy maintenance
• Excellent performance in marine environments
• Availability of spare parts and repair support

---

Frequently Asked Questions

Are IHI HVL hydraulic motors still available?

Yes. Reconditioned units, surplus stock, and spare parts are still available through marine equipment suppliers such as SM MARINE SERVICE™.

Can HVL motors be repaired?

Yes. Most HVL series motors can be overhauled using seal kits, bearings, pistons, and repair components.

What is the difference between HVL and HVK motors?

Both are heavy-duty marine hydraulic motors, but they are used in different crane and winch configurations depending on torque and operational requirements.

Are spare parts available?

Yes. Seal kits, shafts, bearings, piston assemblies, and overhaul kits can still be sourced for many HVL and HVK models.

---
