IHI HVL HYDRAULIC MOTOR

The IHI HVL Hydraulic Motor is one of the most widely used hydraulic motors in IHI Marine Deck Crane Hydraulic Systems. Designed for heavy-duty marine and offshore applications, the HVL Series provides high starting torque, smooth speed control, reliable operation, and long service life under harsh marine environments.

The HVL Series is commonly installed on cargo vessels, bulk carriers, offshore support vessels, and heavy-duty marine cranes where continuous hydraulic performance is essential.

SM MARINE SERVICE™ supplies both New Equipment and Reconditioned Equipment depending on customer requirements.

IHI HVL SERIES COMMON MODELS

The HVL family includes several variants used in different crane capacities and operating conditions:

• HVL
• HVL-SS
• HVL-DSS
• HVL-DT
• HVLP
• HVLG
• HVLK
• HVL-STS

These motors are typically used in:

• Hoisting Systems
• Luffing Systems
• Slewing Systems
• Cargo Handling Cranes
• Offshore Cranes
• Deck Machinery

MANUFACTURER INFORMATION

Manufacturer: IHI Corporation

Country of Origin: Japan

Product Type: Hydraulic Motor

Application: Marine Deck Crane Hydraulic System

Industry: Marine, Offshore, Shipbuilding, Cargo Handling

IHI Corporation is one of Japan's most respected marine engineering manufacturers and has supplied hydraulic crane systems for vessels worldwide for decades.

WHAT IS THE IHI HVL HYDRAULIC MOTOR?

The HVL Hydraulic Motor converts hydraulic energy into rotational mechanical power for operating various crane functions.

The motor is specifically engineered for:

• High Torque Output
• Low-Speed Operation
• Heavy Load Handling
• Continuous Marine Service
• Reliable Offshore Performance

These characteristics make the HVL Series ideal for demanding marine crane operations.

SM MARINE SERVICE™ supports marine hydraulic systems worldwide through equipment supply and technical support.

6

MAIN FEATURES OF IHI HVL HYDRAULIC MOTORS

High Starting Torque

Provides excellent load lifting capability from standstill conditions.

Heavy Duty Construction

Designed to withstand continuous marine operation.

Compact Design

Allows installation in limited crane machinery spaces.

Long Service Life

Manufactured using high-quality materials and precision engineering.

Smooth Speed Control

Provides accurate crane movement and load handling.

Marine Environment Protection

Suitable for operation in saltwater and offshore conditions.

MAIN COMPONENTS

An IHI HVL Hydraulic Motor generally consists of:

• Motor Housing
• Cylinder Block
• Pistons
• Drive Shaft
• Bearings
• Valve Plate
• Seal Assemblies
• Port Plate
• Retaining Components

These parts work together to deliver reliable hydraulic power transmission.

APPLICATIONS OF IHI HVL HYDRAULIC MOTOR

Deck Cranes

The most common application for HVL motors.

Cargo Handling Cranes

Used for loading and unloading operations.

Offshore Cranes

Installed on offshore support vessels and platforms.

Hydraulic Winches

Provides reliable torque for winch systems.

Heavy Marine Machinery

Used where high torque hydraulic drive systems are required.

COMMON TROUBLESHOOTING

Low Torque Output

Possible Causes:

• Internal wear
• Hydraulic leakage
• Low system pressure
• Damaged pistons

Excessive Noise

Possible Causes:

• Bearing damage
• Air in hydraulic system
• Cavitation
• Insufficient lubrication

Oil Leakage

Possible Causes:

• Worn seals
• Damaged shaft seal
• Loose fittings

Overheating

Possible Causes:

• Contaminated oil
• Excessive load
• Restricted hydraulic flow

MAINTENANCE RECOMMENDATIONS

To maximize service life:

• Monitor hydraulic oil cleanliness
• Replace filters regularly
• Check operating pressure
• Inspect shaft seals
• Verify bearing condition
• Monitor oil temperature
• Conduct periodic performance testing

Preventive maintenance significantly reduces crane downtime.

SPARE PARTS AVAILABLE

Common IHI HVL spare parts include:

• Seal Kits
• Bearing Kits
• Drive Shafts
• Pistons
• Cylinder Blocks
• Valve Plates
• Port Plates
• Overhaul Kits
• Repair Kits

SM MARINE SERVICE™ can supply both genuine and high-quality replacement spare parts depending on customer requirements.

WHY MANY SHIPS STILL USE IHI HVL MOTORS

Many vessel operators continue using IHI HVL Hydraulic Motors because of:

• Proven reliability
• Excellent torque performance
• Long service life
• Easy maintenance
• Global spare parts availability
• Strong offshore operational history

FREQUENTLY ASKED QUESTIONS

Can IHI HVL motors be repaired?

Yes. Most HVL motors can be fully repaired and overhauled.

Are reconditioned motors available?

Yes. Reconditioned units are commonly available depending on stock.

Can spare parts be supplied separately?

Yes. Individual spare parts and complete overhaul kits can be supplied.

Can SM MARINE SERVICE™ provide technical support?

Yes. Technical support, troubleshooting assistance, spare parts sourcing, and equipment supply are available.
