KYB Corporation (Kayaba Corporation) – Japan

KYB Corporation, formerly known as Kayaba Industry Co., Ltd., is one of the world's leading manufacturers of hydraulic systems and motion control technologies. Founded in Japan, KYB has earned a strong reputation in the marine, offshore, construction, industrial, and heavy equipment sectors.

The company manufactures:

• Hydraulic Pumps
• Hydraulic Motors
• Hydraulic Power Units (HPU)
• Hydraulic Cylinders
• Hydraulic Control Valves
• Deck Crane Hydraulic Systems
• Mooring Winch Hydraulic Systems
• Windlass Hydraulic Systems
• Hatch Cover Hydraulic Systems
• Offshore Hydraulic Equipment

KYB hydraulic equipment is widely installed on bulk carriers, tankers, container vessels, offshore support vessels, FPSOs, and various marine platforms.

KYB Mooring Winch Hydraulic System

A KYB Mooring Winch Hydraulic System is designed to provide controlled pulling, holding, and releasing of mooring lines during berthing and offshore operations.

The system converts hydraulic power into high-torque rotational force, allowing heavy mooring ropes and wires to be handled safely and efficiently.

6

SM MARINE SERVICE™ supplies KYB hydraulic winch systems, hydraulic motors, pumps, spare parts, and repair services worldwide.

Main Components of a KYB Mooring Winch Hydraulic System

1. Hydraulic Power Unit (HPU)

The HPU acts as the power source of the entire system.

Main components include:

• Electric Motor
• Hydraulic Pump
• Oil Reservoir
• Oil Cooler
• Pressure Gauges
• Accumulator
• Hydraulic Filters
• Control Valves

The HPU continuously supplies pressurized hydraulic oil to the winch system.

2. KYB Hydraulic Pumps

Commonly installed:

• KYB PSV Series Hydraulic Pumps
• Variable Displacement Piston Pumps
• High Pressure Marine Hydraulic Pumps

Functions:

• Generate hydraulic flow
• Maintain operating pressure
• Supply hydraulic energy to the winch motor

3. KYB Hydraulic Motors

Commonly installed:

• KYB MAG Series Hydraulic Motors
• Low-Speed High-Torque Motors
• Winch Drive Motors

Functions:

• Convert hydraulic energy into mechanical torque
• Drive the winch drum
• Control rope handling operations

4

4. Winch Drum Assembly

The drum assembly stores and controls:

• Mooring Wire
• Synthetic Rope
• Combination Rope Systems

The drum is driven directly or indirectly by the hydraulic motor.

5. Hydraulic Brake System

The brake system ensures:

• Safe holding of loads
• Emergency stopping
• Controlled tensioning
• Protection during harsh weather conditions

Working Principle

Step 1

The electric motor drives the KYB hydraulic pump.

Step 2

Hydraulic oil is pressurized inside the HPU.

Step 3

The control valve directs oil flow to the hydraulic motor.

Step 4

The hydraulic motor rotates the winch drum.

Step 5

The drum pulls in or pays out mooring lines.

Step 6

The brake system maintains required line tension.

Typical Applications

KYB Mooring Winch Hydraulic Systems are commonly installed on:

• Bulk Carriers
• Oil Tankers
• Chemical Tankers
• LPG Carriers
• LNG Carriers
• Container Ships
• Offshore Supply Vessels
• FPSO Units
• Jack-Up Rigs
• Offshore Platforms

6

SM MARINE SERVICE™ supports marine operators with spare parts, repairs, and hydraulic system troubleshooting.

Advantages of KYB Mooring Winch Hydraulic Systems

• High Torque Output
• Excellent Reliability
• Smooth Speed Control
• Compact Design
• Long Service Life
• Low Maintenance Cost
• Proven Offshore Performance
• Global Spare Parts Availability
• Heavy-Duty Construction
• Efficient Hydraulic Performance

Common Problems and Troubleshooting

Hydraulic Pump Noise

Possible Causes:

• Low hydraulic oil level
• Air entering suction line
• Contaminated oil
• Pump wear

Hydraulic Motor Not Rotating

Possible Causes:

• Insufficient hydraulic pressure
• Valve malfunction
• Internal motor damage
• Hydraulic blockage

Low Pulling Force

Possible Causes:

• Pump wear
• Motor wear
• Pressure loss
• Relief valve setting issues

Oil Leakage

Possible Causes:

• Damaged seals
• Loose fittings
• Corroded hydraulic lines

High Oil Temperature

Possible Causes:

• Cooler failure
• Dirty filters
• Excessive system load

Preventive Maintenance

Recommended maintenance schedule:

Daily

• Check oil level
• Inspect hoses
• Check pressure readings

Weekly

• Inspect winch drum
• Check brake operation
• Inspect hydraulic connections

Monthly

• Filter inspection
• Valve testing
• Oil contamination analysis

Annually

• Pump overhaul inspection
• Hydraulic motor inspection
• System calibration

Spare Parts Available

SM MARINE SERVICE™ supplies:

• KYB Hydraulic Pumps
• KYB MAG Hydraulic Motors
• Hydraulic Power Units
• Hydraulic Cylinders
• Hydraulic Valves
• Solenoid Valves
• Relief Valves
• Hydraulic Filters
• Accumulators
• Pressure Switches
• Seal Kits
• Shaft Assemblies
• Bearings
• Brake Components
• Oil Coolers
• Hydraulic Hoses

4

Why KYB Systems Remain Popular

KYB hydraulic systems continue to be trusted by shipowners and offshore operators because they offer:

• Japanese Engineering Quality
• Long Operational Life
• Worldwide Service Support
• Proven Marine Performance
• Excellent Spare Parts Availability
• Reliable Hydraulic Technology

SM MARINE SERVICE™ provides complete support for KYB hydraulic systems, including spare parts sourcing, repair, troubleshooting, calibration, and technical assistance.

Frequently Asked Questions

Can KYB hydraulic motors be repaired?

Yes. Most KYB hydraulic motors can be repaired or fully reconditioned depending on their condition.

Can KYB pumps be overhauled?

Yes. Pump overhaul services and spare parts are available.

Does SM MARINE SERVICE™ supply complete KYB winch systems?

Yes. We supply complete systems, HPUs, pumps, motors, valves, and spare parts.

Do you provide onboard troubleshooting?

Yes. Technical support and troubleshooting services are available.

Are reconditioned units available?

Yes. Both new and reconditioned equipment are supplied according to customer requirements.

Short Description

The KYB Mooring Winch Hydraulic System, manufactured by KYB Corporation (Kayaba Corporation), Japan, is a reliable marine hydraulic solution designed for mooring operations on commercial and offshore vessels. Utilizing KYB hydraulic pumps, motors, control valves, and hydraulic power units, the system delivers high torque, smooth operation, and long-term reliability in demanding marine environments.
