GRAVINER Mark 6 OMD
GRAVINER
New product
The Graviner Mark 6 Oil Mist Detector (OMD) is one of the most widely recognized crankcase protection systems used onboard commercial vessels worldwide. Developed by Kidde Graviner, the Mark 6 OMD continuously monitors oil mist concentration inside diesel engine crankcases and provides early warning of abnormal operating conditions that may lead to serious machinery damage or crankcase explosions.
Oil mist is generated naturally within diesel engine crankcases. Under normal operating conditions, oil vapor generation and condensation remain balanced. However, when a bearing begins overheating, piston seizure develops, or another mechanical fault creates a hotspot, oil mist levels increase rapidly. If not detected early, this condition may result in an explosion inside the crankcase. The Mark 6 OMD is specifically designed to identify these dangerous conditions before they become critical.
The Graviner Mark 6 introduced a modern detector-based architecture that eliminates traditional sample piping systems, reducing installation complexity while improving monitoring speed and reliability. The system is approved and installed on thousands of vessels including container ships, tankers, bulk carriers, offshore vessels, and power generation installations.
The Graviner Mark 6 OMD is an analogue addressable oil mist detection system designed to monitor diesel engine crankcases without the need for external sampling pipes. Each detector head is mounted directly on the engine crankcase and independently measures oil mist density. The measured data is transmitted digitally to the control unit for continuous analysis and alarm management.
A complete Mark 6 OMD system generally consists of:
The system can monitor up to 64 detector heads installed across up to 8 separate engines from a single control panel. This allows simultaneous monitoring of main propulsion engines and auxiliary generators using one integrated system.
The detector uses optical light-scattering technology. Oil mist particles scatter a controlled light beam, and the detector electronics calculate the oil mist density. If alarm thresholds are exceeded, the control unit activates visual alarms, audible alarms, and engine protection outputs.
Each detector head is mounted directly on the crankcase, eliminating the need for sample pipes and associated maintenance requirements.
A single Mark 6 control unit can supervise up to eight engines and sixty-four detector heads simultaneously.
The system can scan a complete 64-detector installation in approximately 1.2 seconds, providing rapid response to developing engine faults.
The Mark 6 utilizes light scattering measurement principles that provide high sensitivity while maintaining strong resistance to false alarms.
Each detector head operates independently and can be identified, monitored, isolated, and replaced without affecting the remaining detectors on the system.
The system provides early warning of overheating bearings, piston failures, crankshaft problems, and other developing mechanical faults before catastrophic failure occurs.
The control unit records alarm events, detector status information, and system diagnostics to support maintenance and fault analysis.
| Parameter | Specification |
|---|---|
| Product Name | Oil Mist Detector |
| Model | Mark 6 OMD |
| Manufacturer | Kidde Graviner |
| Equipment Type | Crankcase Oil Mist Detection System |
| Monitoring Capacity | Up to 64 Detector Heads |
| Engine Capacity | Up to 8 Engines |
| Detection Principle | Optical Light Scattering |
| Detector Communication | Digital Addressable |
| Detector Protection | IP65 |
| Detector Power Consumption | Approx. 2.8 W |
| Detector Operating Temperature | 0°C to 70°C |
| System Function | Crankcase Explosion Prevention |
| Application | 2-Stroke and 4-Stroke Diesel Engines |
Technical specifications based on Graviner Mk6 technical documentation.
The Graviner Mark 6 OMD is used extensively throughout the marine industry.
Provides protection for main propulsion engines and auxiliary generators.
Monitors crankcase conditions and assists with early fault detection.
Provides critical engine protection during long operating periods and heavy engine loading.
Supports safe machinery operation and compliance with engine manufacturer recommendations.
Provides continuous crankcase monitoring for propulsion and power generation equipment.
Protects engines used for propulsion, dynamic positioning, and power generation.
Supports machinery safety and operational reliability.
Ensures protection of specialized propulsion and generator systems.
Monitors auxiliary and propulsion engines operating under demanding conditions.
The Mark 6 OMD is frequently integrated with:
SM MARINE SERVICE™ supports sourcing and supply of:
Both genuine replacement parts and reconditioned units may be available depending on customer requirements and stock availability.
SM MARINE SERVICE™ provides complete technical support for Graviner Mark 6 OMD systems.
Diagnosis of:
Professional repair services for control panels, detector heads, junction boxes, power supplies, communication modules, and electronic assemblies.
System verification, detector testing, and operational performance validation.
Functional testing of detector heads, control units, communication networks, and alarm outputs.
Complete refurbishment, cleaning, inspection, component replacement, and performance verification.
Support may be available for:
Our engineers provide workshop repairs and onboard attendance services for vessels worldwide.
SM MARINE SERVICE™
Bangladesh Office
Samir Market, DT Road, Pahartali, Beside CDA Market, Chattogram, Bangladesh
China Warehouse and Support Center
Shanghai, China
SM MARINE SERVICE™ supplies both New Equipment and Reconditioned Equipment depending on customer requirements and budget.
We provide worldwide supply, sourcing, repair, calibration, technical support and spare parts services for marine automation, navigation, communication and marine electronic systems.
Website : https://www.smmarineservice.com
Email : info@smmarineservice.com
WhatsApp and Viber : +8801818929292
Marketing Contact: Nazmul Hasan Bhuiyan
Mobile WhatsApp and Viber : +8801730296909
The Graviner Mark 6 Oil Mist Detector remains one of the most trusted crankcase protection systems in the global marine industry. Its advanced detector technology, multi-engine monitoring capability, rapid response time, and reliable alarm management help prevent serious engine damage and reduce the risk of crankcase explosions.
For Graviner Mark 6 OMD supply, repair, calibration, troubleshooting, spare parts, reconditioned equipment, technical documentation support, and worldwide marine services, contact SM MARINE SERVICE™. Our experienced marine automation specialists provide professional support solutions for shipowners, ship managers, chief engineers, and marine operators worldwide.
