SAACKE DREHANTRIEB HD 60 D2 SERVOMOTOR HD60D2
SAACKE
New product
The SAACKE Drehantrieb HD 60 D2 Servomotor is a precision-engineered rotary actuator developed by SAACKE GmbH, Germany, for marine boiler combustion control applications. From the nameplate visible on the supplied equipment, the actuator is identified as Drehantrieb HD 60 D2, operating on 230 VAC, with a 20 Nm torque output, 120° travel angle, and 88-second positioning time.
Marine auxiliary boilers remain essential equipment onboard commercial vessels. They provide steam for fuel oil heating, cargo heating, tank cleaning, accommodation services, freshwater production systems, and numerous engine room processes. The efficiency and safety of these boilers depend heavily on accurate combustion control.
The HD60D2 servomotor is designed to control the movement of burner air dampers, fuel regulating mechanisms, and combustion control linkages. By accurately positioning these components, the actuator helps maintain the correct combustion ratio required for efficient steam production.
Reliable actuator performance contributes directly to fuel savings, lower emissions, improved boiler efficiency, and safer vessel operation. This is why SAACKE burner actuators are widely installed aboard container vessels, tankers, bulk carriers, offshore units, and passenger ships around the world.
The SAACKE HD60D2 is an electric rotary actuator specifically designed for integration into combustion control and burner management systems.
Its primary purpose is to convert electrical control commands into controlled mechanical rotation. When a signal is received from the burner management system, the actuator rotates its output shaft to the required position, adjusting airflow or fuel flow according to the boiler's operating demand.
This positioning process ensures optimum combustion efficiency throughout the boiler's load range.
The actuator is commonly integrated with:
Because combustion efficiency directly affects vessel operating costs, the HD60D2 plays a significant role in reducing fuel consumption and improving boiler performance.
Its proven reliability has made it a preferred solution for marine engineers and ship operators seeking dependable burner automation equipment.
The HD60D2 provides accurate rotary movement, ensuring stable and repeatable positioning of combustion control mechanisms.
With a rated torque output of 20 Nm, the actuator can operate burner dampers and fuel control components efficiently under demanding conditions.
Marine boiler systems often operate continuously for extended periods. The HD60D2 is engineered to deliver dependable long-term performance under such conditions.
Accurate control of air and fuel ratios improves combustion quality, reduces fuel waste, and supports cleaner boiler operation.
The actuator is built to withstand vibration, temperature variations, and harsh marine environments commonly encountered in engine rooms.
The unit can be incorporated into both existing and newly installed SAACKE boiler automation systems.
Its robust design and proven engineering contribute to lower maintenance costs and improved operational reliability.
| Parameter | Specification |
|---|---|
| Manufacturer | SAACKE GmbH |
| Model | Drehantrieb HD 60 D2 |
| Equipment Type | Rotary Electric Actuator |
| Application | Marine Boiler Burner Control |
| Rated Torque | 20 Nm |
| Travel Angle | 120° |
| Positioning Time | 88 Seconds |
| Supply Voltage | 230 VAC |
| Frequency | 50/60 Hz |
| Power Consumption | 6.6 W |
| Protection Class | IP54 |
| Installation Environment | Marine and Industrial |
| Country of Manufacture | Germany |
The specifications listed above are based directly on the actual equipment nameplate visible in the supplied image.
The HD60D2 is used in auxiliary boiler systems supporting fuel treatment and vessel utility services.
Provides combustion control for boilers supplying steam during cargo and voyage operations.
Supports cargo heating systems where reliable steam generation is essential.
Used in boiler systems that maintain cargo temperature and support onboard thermal processes.
Installed in auxiliary steam systems supporting vessel operations.
Provides dependable burner positioning for boiler control equipment.
Used in utility boilers and thermal oil heating systems supporting offshore activities.
Supports accommodation steam services and hotel load requirements.
Provides combustion control for scientific and operational support systems.
Used in vessels equipped with auxiliary boilers and heating systems.
The SAACKE HD60D2 actuator can operate alongside:
SM MARINE SERVICE™ provides global sourcing and supply support for SAACKE marine boiler automation equipment.
Available support includes:
Our sourcing team assists ship owners, ship managers, chief engineers, technical superintendents, and marine purchasing departments worldwide.
SM MARINE SERVICE™ offers comprehensive support for SAACKE burner control and boiler automation systems.
Services include:
We also assist customers with:
Our marine engineering team can evaluate the actuator condition and recommend repair, overhaul, calibration, or replacement solutions according to vessel requirements.
SM MARINE SERVICE™
Bangladesh Office
Samir Market, DT Road, Pahartali, Beside CDA Market, Chattogram, Bangladesh
China Warehouse and Support Center
Shanghai, China
SM MARINE SERVICE™ supplies both New Equipment and Reconditioned Equipment depending on customer requirements and budget.
We provide worldwide supply, sourcing, repair, calibration, technical support and spare parts services for marine automation, navigation, communication and marine electronic systems.
Website : https://www.smmarineservice.com
Email : info@smmarineservice.com
WhatsApp and Viber : +8801818929292
Marketing Contact: Nazmul Hasan Bhuiyan
Mobile WhatsApp and Viber : +8801730296909
The SAACKE Drehantrieb HD 60 D2 Servomotor HD60D2 is a critical component within marine boiler combustion control systems, delivering accurate positioning, dependable operation, and long-term reliability. Its robust design, 20 Nm torque capability, and proven performance make it an ideal solution for controlling burner dampers and combustion mechanisms onboard commercial vessels.
For supply, repair, calibration, spare parts, technical support, troubleshooting assistance, reconditioned equipment, and worldwide marine services related to SAACKE HD60D2 actuators and marine boiler automation systems, contact SM MARINE SERVICE™. Our experienced marine engineering team is ready to support your vessel with professional technical solutions and global spare parts sourcing services.
