Marine Telephone
Zenitel,Norway
New product
The VINGTOR-STENTOFON VSP-211-L is a 12-way batteryless marine telephone main station designed for reliable onboard communication, particularly when the vessel’s normal electrical communication systems are unavailable.
Manufactured under the VINGTOR-STENTOFON brand and developed by Zenitel, the VSP-211-L is part of the established VSP 12-Way Batteryless Telephone System. Its manually operated call generator and built-in amplified communication circuit allow selected stations to communicate during a vessel blackout or other emergency condition.
The photographed unit carries the nameplate item number 1020600931.0600, corresponding to the official VSP-211-L base item number 1020600931. The label also states that the product was designed and developed by Zenitel in Norway and assembled in Poland.
Image 1 – Main Product Image
Suggested ALT text: VINGTOR-STENTOFON VSP-211-L 12-way batteryless marine telephone
Suggested caption: VINGTOR-STENTOFON VSP-211-L batteryless telephone main station with handset, line selector and hand-operated call generator.
| Information | Details |
|---|---|
| Manufacturer | Zenitel |
| Brand | VINGTOR-STENTOFON |
| Country of Brand Origin | Norway |
| Assembly Location on Photographed Unit | Poland |
| Exact Model | VSP-211-L |
| Official Item Number | 1020600931 |
| Nameplate Item Number | 1020600931.0600 |
| Product Type | Main Station – Batteryless Telephone System |
| System Capacity | 12-way system |
| Mounting Type | Flush mounted; optional wall or desk mounting |
| Primary Application | Onboard emergency and secondary voice communication |
| Suitable Locations | Wheelhouse, bridge and control room |
| Protection Rating | IP44 when installed in a console |
| Colour | Black |
Reliable internal communication is essential for vessel safety. During a total blackout, conventional telephone exchanges, powered intercoms and other communication equipment may become unavailable unless supported by a functioning emergency power source.
The VSP-211-L provides an independent and mechanically initiated communication method. A shipboard operator selects the required station using the 12-position line selector and turns the hand crank to generate the calling signal. The called station receives an audible indication, allowing personnel at different locations to establish voice communication.
The VSP-211-L contains the system amplifier and capacitor-based energy storage arrangement used by the VSP 12-Way system. It is therefore an important main station within the complete network and should not be replaced by a different VSP station type without checking the vessel’s original wiring and system configuration.
The VSP-211-L is a panel-mounted main telephone station for the VINGTOR-STENTOFON VSP 12-Way Amplified Batteryless Telephone System.
A complete 12-way installation can include up to 12 connected stations. Every station is assigned an individual extension number, and the operator selects the intended extension using the rotary line selector.
The system does not depend on normal vessel power for its basic calling and communication functions. Mechanical operation of the crank generates the call energy, while the main station’s built-in amplifier and capacitor battery support voice communication.
Terminals are also available for an auxiliary 24 VDC supply when the units are used as common-battery telephones. Zenitel specifies that any auxiliary 24 VDC supply should be provided through an appropriate DC/DC converter to prevent electrical noise.
Image 2 – Nameplate Close-up
Suggested ALT text: Zenitel VINGTOR-STENTOFON VSP-211-L item number 1020600931.0600 nameplate
Suggested caption: Product nameplate confirming model VSP-211-L, item number 1020600931.0600, Zenitel Norway design and assembly in Poland.
The standard calling procedure is:
According to the VSP 12-Way technical instructions, approximately five to six crank rotations may be required to generate a strong calling signal.
The operating instructions printed on the front panel also remind the user to keep the handset talk button pressed during the conversation.
| Specification | Verified Information |
|---|---|
| Model | VSP-211-L |
| Item Number | 1020600931 |
| System Type | VSP 12-Way Batteryless Telephone System |
| Station Function | Main station with system amplifier |
| Station Selection | 12-position rotary selector |
| Connections | Screw terminals |
| Colour | Black |
| IP Rating | IP44 when installed in a console |
| Dimensions | 238 × 205 × 137 mm, including handset and built-in depth |
| Panel Cut-out | 205 × 105 mm |
| Weight | Approximately 1.30 kg |
| Operating Temperature | –25°C to +55°C |
| Compass Safe Distance | More than 155 cm |
| Standard Mounting | Flush mounting |
| Optional Mounting | Wall or desk mounting with appropriate cabinet |
| Optional Supply | Auxiliary 24 VDC through a suitable DC/DC converter |
Specifications should always be checked against the vessel’s current drawings and the latest manufacturer documentation before replacement or installation.
The VSP-211-L normally incorporates the following main functional components:
Internal components, PCB versions and connection arrangements may vary with manufacturing revision. Replacement parts should therefore be matched using the complete model, item number, existing terminal configuration and photographs of the original unit.
Verified equipment within or associated with the VSP 12-Way family includes:
Compatibility must be confirmed from the vessel’s existing system arrangement before ordering.
The VSP-211-L can be installed as part of a secondary communication network aboard:
Typical communication locations may include:
The precise station arrangement depends on the vessel design, classification requirements and approved communication plan.
Possible causes include an incorrect extension address, loose terminal connections, damaged cabling or an internal station fault.
Recommended checks:
When several stations fail simultaneously, inspect the common wiring route, junction box and shared conversation lines.
Check for:
If the called station does not ring or produce an audible signal:
Possible causes include:
If auxiliary 24 VDC is connected, confirm that an appropriate DC/DC converter is being used.
Inspect the push-to-talk button, handset microphone, receiver, conversation-line wiring and internal audio connections. A defective handset cable can cause intermittent or one-way audio.
Intermittent performance may result from:
Check cable screening, grounding and terminal condition. The cable screen should be connected according to the official VSP wiring instructions. Any auxiliary DC power source must also comply with Zenitel’s installation requirements.
The VSP-211-L does not use a digital display and does not normally present numerical alarm codes. Its main indications are associated with incoming calling and external signalling.
Depending on the installation, an incoming call may activate:
The ALARM STOP control is used to acknowledge or stop the relevant call indication according to the installed system configuration.
No numerical fault codes should be assigned to this model unless they are documented for a specific connected accessory or vessel installation.
SM MARINE SERVICE™ can support the sourcing of the VINGTOR-STENTOFON VSP-211-L complete main station and related VSP system equipment, subject to stock and market availability.
Possible supply requirements include:
SM MARINE SERVICE™ can assist with sourcing:
For accurate matching, buyers should provide the complete model number, item number, front and rear photographs, internal connection photographs and details of the vessel’s existing VSP system.
Before replacing a VSP-211-L, verify:
A VSP-213-L or another physically similar station should not automatically be treated as a direct functional replacement for the VSP-211-L because the VSP-211-L contains the system amplifier.
The VSP-211-L continues to be important because it provides communication without relying entirely on the vessel’s normal electrical supply or digital network.
Its key operational advantages include:
For vessels already equipped with a VSP 12-Way system, repairing or replacing the correct station is often more practical than modifying the complete approved communication installation.
The VSP-211-L is a main station for the Zenitel VSP 12-Way Amplified Batteryless Telephone System. It includes a 12-position line selector, manually operated calling generator and built-in system amplifier.
The product is manufactured under the VINGTOR-STENTOFON brand and developed by Zenitel. Zenitel is a Norwegian marine communication equipment manufacturer.
The official base item number is 1020600931. The photographed equipment carries the extended item number 1020600931.0600, which may identify its manufacturing or configuration revision.
No. It is part of a batteryless shipboard telephone system designed to provide secondary communication during loss of normal vessel power.
The VSP 12-Way system supports up to 12 stations, with selective calling between the connected extensions.
Yes. The VSP-211-L is the main station equipped with the built-in system amplifier and capacitor-based energy storage arrangement.
It is suitable for flush installation in a wheelhouse, bridge console or control room. Optional cabinets can support wall or desk mounting.
The official specification lists an IP44 rating when the unit is properly installed in a console.
The verified operating temperature range is –25°C to +55°C.
The station should be installed more than 155 cm away from the vessel’s magnetic compass.
Yes. SM MARINE SERVICE™ can assist with used, refurbished, reconditioned and tested working VSP-211-L units, subject to availability and technical matching.
Availability varies because some internal parts may depend on the equipment revision. Complete units, handsets, cables, generators, selector assemblies, electronic parts and associated VSP accessories may be sourced subject to stock.
Common problems include no calling signal, weak or distorted audio, incorrect extension selection, handset-cable failure, selector-switch problems, loose terminals, wiring faults, generator failure and internal amplifier faults.
Not automatically. Although both belong to the VSP 12-Way family, the VSP-211-L performs the main-station amplifier function. Any substitution must be confirmed against the system design and technical documentation.
SM MARINE SERVICE™ can support international buyers with sourcing, inspection, testing, spare parts and worldwide shipment of VSP-211-L equipment, depending on availability.
Yes. Worldwide supply and shipping support can be arranged for shipowners, ship managers, shipyards, marine service companies, technical managers and spare-parts buyers.
The VINGTOR-STENTOFON VSP-211-L, item number 1020600931, is a 12-way batteryless marine telephone main station developed by Zenitel for reliable shipboard secondary and emergency communication. It features a 12-position line selector, manual call generator, marine handset, built-in system amplifier, capacitor-based energy storage and optional auxiliary 24 VDC connection. SM MARINE SERVICE™ can support the worldwide supply of new, used, refurbished, reconditioned and tested VSP-211-L units and spare parts, subject to availability.
View Official Zenitel Product Page
This page provides the official product description, specifications, dimensions, accessories and available manufacturer documentation.
Download Official Zenitel VSP-211-L Datasheet
The official datasheet includes the product description, verified technical specifications and dimension information.
Zenitel lists the latest A100K10873 VSP 12-Way Technical Manual on the official product page. A Zenitel account or login may be required to download the current version.
Access the Manual Through the Official Product Page
The official VSP 12-Way Quick Guide covers extension configuration and basic operation. Zenitel may require login for direct downloading.
View Zenitel Batteryless Telephone Documentation
Download Zenitel VSP DNV Type Approval Certificate
Always use the latest manufacturer manual and current classification documentation when installing, modifying or servicing the system.
